UFM Infra

The UFM Infra feature introduces a structured architecture where services are divided into two categories, each deployed differently based on functionality:

• UFM Infra: A set of persistent infrastructure services that run on all nodes. These services support system-level operations and ensure distributed availability.

• UFM Enterprise: Services that run exclusively on the master node, responsible for management, orchestration, and user-facing functionality.

Key Benefits

• Faster API Availability after Failover: By limiting service transitions during node failures, recovery times are significantly reduced.

• Improved Modularity: Separating core infrastructure from enterprise logic simplifies maintenance and troubleshooting.

• Enhanced Scalability: Services can be scaled and managed independently across nodes.

Users can enable or disable the UFM Infra feature without requiring a reinstallation of the UFM system. For more information, refer to UFM Infra | id (6.24.2)UFMInfra EnablingorDisablingUFMInfra.
Installation instructions are available at UFM Infra Installation.

Pre-Requirement

The Valkey image must be loaded, or the is_external_redis flag must be enabled in gv.cfg.

Service Architecture

ufm-infra.service

Manages the following infrastructure components:

ufm-enterprise.service

Manages the following enterprise components:

Shared Resources

In Infra mode, the following resources are shared between services:

• Docker Volume (ufm-shared-data) (ufm-shared-data): Shared Apache configuration between containers

• Shared Configuration Files: opt/ufm/files/mounted to both containers

• Valkey: Used for topology publishing and inter-service communication

Configuring UFM Infra

Fast-API configuration

The following parameters can be modified within the Fast API configuration file:

Enabling or Disabling UFM Infra

UFM Infra mode can be enabled or disabled after installation using the ufm_infra_feature_flag.py script.

Script Location

/opt/ufm/files/scripts/ufm_infra_feature_flag.py

Command Line Options

Usage:

ufm_infra_feature_flag.py[-h](
    -e | -d)[--rootless][--log - level{DEBUG, INFO, WARNING, ERROR, CRITICAL}]
            [--timeout - seconds TIMEOUT_SECONDS][--ufm - user UFM_USER]
            [--force][--skip - ha - validation]
            [--infra - plugins - dir<path>] Control UFM Infra feature flags

Enabling Infra Mode

Standalone Mode (Docker)

Without Automatic Service Management

1. Stop UFM services manually:

   systemctl stop ufm-enterprise systemctl stop ufm-infra





2. Enable Infra mode:

   cd /opt/ufm/files/scripts/ ./ufm_infra_feature_flag.py --enable





3. Start UFM services manually:

   systemctl start ufm-infra systemctl start ufm-enterprise


   The script automatically detects whether the system is running in HA mode and manages cluster resources accordingly.

Disabling Infra Mode

Standalone Mode (Docker)

cd /opt/ufm/files/scripts/ ./ufm_infra_feature_flag.py --disable --force

Standalone Mode (Rootless Podman)

cd /opt/ufm/files/scripts/ ./ufm_infra_feature_flag.py --disable --rootless --force

High Availability (HA) Mode

cd /opt/ufm/files/scripts/ ./ufm_infra_feature_flag.py --disable --force

Script Behavior

When Enabling Infra Mode

The script performs the following actions:

• Stops UFM services (standalone) or the HA cluster

• Waits for all UFM containers to stop

• Updates gv.cfg to set:

  [UFMInfra] enabled = true





• Updates the Valkey trigger file to enabled

• Validates HA resources (if running in HA mode)

• Loads and installs Infra plugins if --infra-plugins-dir is specified

• Restarts UFM services or the HA cluster

When Disabling Infra Mode

The script performs the following actions:

• Stops UFM services (standalone) or the HA cluster

• Waits for all UFM containers to stop

• Updates gv.cfg to set:

  [UFMInfra] enabled = false





• Updates the Valkey trigger file to disabled

• Restarts UFM services or the HA cluster

Communication Flow: Fast API, Valkey, SM/SHARP Components

As part of the updated architecture, a FAST-API plugin can be deployed as an Infra Plugin and a Valkey server is required for inter-service communication. Valkey can be configured in two ways:

• As an internal service (installed with UFM)

• As an external Redis/Valkey instance, depending on deployment needs.

The following sequence describes how communication is handled between Fast API, Valkey, and SM/SHARP components:

1. Request Submission via Fast API
   Users send REST API requests (e.g., for PKey creation or SHARP reservation actions) to the Fast API. These requests are placed into Valkey queues, and a Transaction ID (TID) is returned to the user for tracking purposes.

2. Processing by Communicators

   • The SM Communicator or SHARP Communicator monitors Valkey queues for new requests.

   • Upon receiving a request, the communicator forwards it to the relevant component (SM or SHARP) for execution.

   • After processing, the communicator captures the response and status.

3. Status Updates
   The communicators update the status of each request back into Valkey. Users can query the status of their transaction using the TID provided during request submission.

4. Configuration Storage and Retrieval

   • Communicators store the configuration in Valkey.

   • This allows the Fast API to retrieve and expose configuration data via REST APIs, giving users access to the configuration via REST APIs to understand cluster-level settings.
