Technical Specifications

Size

2U:

• Height – 88 mm (3.46 inches)

• Width – 438.4 mm (17.25 inches)

• Depth – 809 mm (35.4 inches)

Weight

39.2kg

Mounting

MGX

DC input voltage

42 Vdc to 58 Vdc

CPU

2 x Intel Xeon Gold 6548Y+

Maximum

1505W

InfiniBand/Ethernet

Auto-negotiation:

• X/2X/4X SDR (2.5Gb/s per lane)

• DDR (5Gb/s per lane)

• QDR (10Gb/s per lane)

• FDR10 (10.3125Gb/s per lane)

• FDR (14.0625Gb/s per lane)

• EDR (25Gb/s per lane) port

• HDR (50Gb/s per lane) port

• NDR (400Gb/s per lane)

• XDR (400Gb/s per lane)

Ethernet: 400GAUI-8 C2M, 400GBASE-CR8, 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2, 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M , XLPPI, SFI

SGMII Data Rate: SDR

Data Rate

InfiniBand – SDR/DDR/QDR/FDR/EDR/HDR/NDR

Ethernet – 1/10/25/40/50/100/200/400 Gb/s

Hard Drives

2 x 7.68TB E1.S NVMe Mixed Use, Hot-Plug, SED Drive and 2x M.2 960GB NVMe, SED Drive

Memory

16x64GB DDR5-5600MT/s, RDIMM

Temperature

Operating

10-35°C

Non-operating

-30-60°C

Humidity

Operating

8-80% (non-condensing)

Non-operating

8-90% (non-condensing)

Vibration (5 ~500 Hz)

0.21gr

Shock

5G (with 10 ms duration, half-sine wave)

Thermal

Airflow

30 CFM

Maximum heat dissipation

5153 BTU/hour
